Compact Panel Radiator - 1600x600 mm
Commercial-grade 1600x600 mm steel panel radiator delivering 3223W heat output with maximum energy efficiency and heavy-duty anti-corrosion coating. Perfect for standard large rooms.
Heat Output (90/70/20°C)
Radiator Length
Radiator Height
Warranty
Overview
The Compact Panel Radiator 1600x600 mm is engineered for standard large room heating requirements. Its quality steel construction and eco-friendly coating provide durability and efficiency. The radiator is simple to install and maintain, with a timeless design.
Highlights
Engineered for standard large rooms
Handles standard large room heating requirements efficiently.
Energy efficient
Designed to minimize energy use.
Eco-friendly anti-corrosion coating
Protects against rust and is environmentally safe.
Perfect for standard large rooms
Sized optimally for standard large residential spaces.
Features
Quality Steel Construction
Provides durability and efficiency.
Eco-Friendly Coating
Protects against corrosion and is environmentally safe.
Simple Installation
Easy to install and maintain.
Timeless Design
Fits any room style.
Specifications
| Key | Value |
|---|---|
| Radiator Height | 600 mm |
| Radiator Length | 1600 mm |
| Heat Output (90/70/20°C) | 3223 W |
| Heat Output (75/62/20°C) | 2535 W |
| Heat Output (55/45/20°C) | 1294 W |
| Water Volume | 11.4 L |
| Empty Net Weight | 48.6 kg |
| Material | Quality steel sheet |
| Panel Thickness | 1.25 mm |
| Color | Classic white (RAL9010) |
| Corrosion Protection | Environmentally friendly anti-corrosion coating |
| Packaging | Recyclable protective packaging |
| Standards Compliance | DIN EN 442 |
| Test Pressure | 13 bar |
| Max Operating Pressure | 10 bar |
| Max Water Temperature | 110°C |
| Warranty | 5 years |
| Connection Points | 4 |
